26-Inch UTV Soundbar Installation Guide

Many UTV owners add a soundbar for trail rides, weekend trips, and time around camp without rebuilding the whole audio system. The Manrock 6-Speaker 26" RGB Sound Bar Audio System fits Can-Am Maverick X3 and Polaris RZR models with a 1.75-2.25 inch roll cage. This guide follows the attached 26-Inch RGB Bluetooth Soundbar Installation Manual and adds practical notes for a cleaner mount and safer wire routing.

👉UTV 6 Speaker 26'' RGB Sound Bar Audio System

👉Installation Manual: Click Here

Before Installation

Park the UTV on level ground and turn the vehicle off. Check the roll cage tube where the soundbar will mount. The Installation Manual shows the soundbar installed on the upper rear roll-cage tubes.

Lay the parts on a clean surface and confirm the package contents:

• 26-Inch Soundbar x 1
• Remote Control x 1
• Installation Tool x 1
• Lower Clamp Bracket x 2
• Upper Clamp Bracket x 2
• Slide Block x 2
• Locknut x 2
• Short Bolt x 2
• Long Screw x 4
• Anti-Vibration Pad x 2
• Power Extension Cable x 1

Keep the clamp hardware loose at the beginning. The slide blocks need to be positioned in the soundbar channel before the brackets are fully tightened.

Installation Steps

Step 1: Attach the Slide Blocks to the Lower Clamp Brackets

Start by assembling the mounting brackets on a work surface. Use the short bolts and locknuts to attach each slide block to a lower clamp bracket.

Leave the hardware loose for now. The slide blocks still need to slide into the channel on the back of the soundbar, so do not lock the brackets down too early.

Step 2: Attach the Slide Blocks to the Soundbar

Slide the assembled bracket pieces into the channel on the back of the soundbar. Position each slide block so the clamps line up with the upper rear roll-cage tubes.

Once the bracket locations look correct, tighten them securely. Check that both brackets sit evenly so the soundbar hangs level after mounting.

Step 3: Apply the Anti-Vibration Pads

Apply one anti-vibration pad to each clamp mounting location. The pads should sit between the clamp area and the roll-cage tube contact point shown in the Installation Manual.

Press the pads into place before lifting the soundbar into the vehicle. Even pad placement helps the clamps seat cleanly when the soundbar is tightened.

Step 4: Mount the Soundbar on the Upper Rear Roll-Cage Tubes

Lift the soundbar into position on the upper rear roll-cage tubes. Hold it steady while installing the upper clamp brackets over the tubing.

Install the upper clamp brackets and tighten all fasteners securely. Keep the soundbar centered and level while tightening, and make sure the brackets clamp evenly around the roll-cage tubes.

Step 5: Connect the Power Extension Cable

Connect the power extension cable to the soundbar power lead. Make sure the connector is fully seated before routing the cable toward the battery area.

Keep the wire path clean and away from sharp edges, pinch points, and moving parts. Leave enough slack for normal vehicle movement and vibration.

Step 6: Move the Front Passenger Seat Forward

Slide the front passenger seat forward to access the battery, as shown in the Installation Manual.

Before connecting the wiring, check that the cable route from the soundbar to the battery is clear. A clean route along the roll cage helps keep loose wiring out of the cab.

Step 7: Route the Wiring Harness and Connect the Battery Leads

Route the wiring harness along the roll cage to the battery beneath the passenger seat. Connect the red power wire to the positive (+) battery terminal and the black wire to the negative (-) battery terminal.

After connecting the leads, check that the wiring is not stretched or rubbing against sharp surfaces. Secure the cable path as needed so the harness stays in place during normal riding.

Step 8: Check the Soundbar After Installation

Once the mounting hardware and power wiring are complete, turn the vehicle on and check that the soundbar powers up.

Use the controls or remote to confirm basic operation. If the soundbar does not power on, recheck the power extension connection and the battery terminal connections before riding.

Final Installation Check

Before heading out, inspect the setup one more time:

• The soundbar is mounted on the upper rear roll-cage tubes.
• The upper and lower clamp brackets are tight.
• Red is connected to positive (+), and black is connected to negative (-).
• The wiring harness is routed away from sharp edges, pinch points, and moving parts.
• The soundbar powers on and stays secure when checked by hand.

If anything shifts, rattles, or feels loose, adjust the position and retighten the fasteners before driving.

Installation Tips

Build the lower clamp and slide block assemblies before lifting the soundbar into the UTV. It is much easier to position the slide blocks in the rear channel while the soundbar is still on a work surface.

Have a second person hold the soundbar during the roll-cage mounting step if possible. A 26-inch audio bar is easier to level and secure when one person supports the unit and the other installs the upper clamp brackets.

Check the cable path before making the battery connection. A clean route along the roll cage helps keep the harness out of the seating area and away from spots where it could get pinched.

Conclusion

The Manrock 26-Inch RGB Bluetooth Soundbar installs with clamp brackets and a direct battery connection. Start by assembling the lower clamp brackets and slide blocks, attach them to the soundbar, add the anti-vibration pads, mount the unit on the upper rear roll-cage tubes, and connect the wiring to the battery.

After installation, check the brackets, wire routing, and power connection before riding.

FAQ

Q1: Do I need to tighten the lower clamp brackets before sliding them into the soundbar?
A1: No. Keep the lower clamp bracket hardware loose at first. Slide the blocks into the soundbar channel, set the bracket positions, and then tighten them securely.

Q2: Where does the soundbar mount on the UTV?
A2: The Installation Manual shows the soundbar mounted on the upper rear roll-cage tubes. Confirm that the roll cage tube is within the 1.75-2.25 inch fitment range before installing the clamps.

Q3: How should the power wires connect to the battery?
A3: Route the wiring harness along the roll cage to the battery beneath the passenger seat. Connect red to positive (+) and black to negative (-), following the Installation Manual.
